The Linx 7900 Swift continuous inkjet printer is a high speed printer designed to give clear legible codes at line speeds of up to 6.83m/s, with up to 2 lines of print.
A narrow font option is available for coding onto small print areas e.g. bottle tops.
With a choice of IP55 (washdown) and IP65 (dust proof) rated enclosures, the Linx 7900 Swift high speed printer works reliably in virtually any production conditions.
The Linx 7900 Swift industrial ink jet printer for coding and marking comes with everything you expect as standard:
• No hidden costs
• Long service intervals of up to 18 months or 9000 hours
• 18 month warranty
Take more control of your production line with Linx Insight®. This remote web interface allows you to monitor your Linx 7900 from a smart phone, plus download or upload messages from a PC. And Linx Insight is included with the printer at no extra cost. All you need is internet access on your PC or smart phone, and an ethernet connection to the printer.
Simple printer control
• Remote printer monitor and control with Linx Insight
• Quick code changes using a barcode scanner and QuickSwitch® software
• Easy transfer of messages between printers with a standard USB port or using Linx Insight
Lowest running costs
• Long service intervals of up to 9000 hours or 18 months
• 18 month warranty
• Minimal parts changed at scheduled services – no expensive ink system assemblies to replace, so no hidden costs
Increased production uptime
• Automatic and thorough cleaning of the printhead and conduit at every shutdown.
• Linx’s unique FullFlush® system ensures reliable startups
• Fast mistake proof refills with the SureFill® system
Extra features – as standard
• Ethernet port
• Data Matrix 2D codes
• RS232 connectivity
• External single stage alarm output
• Connectivity for product detectors and shaft encoders |
|
Printing capability
• Up to 2 lines of text, graphics, logos, barcodes
• 2 lines as standard
• Maximum print speed of 6.83m/s (for single line of code)
• Print heights from 1.4mm to 6.7mm
• Narrow fonts for coding onto small print areas
• Data Matrix 2D codes
• Dynamic reverse/invert printing for traversing lines
Programming facilities
• Linx Insight remote printer control and status view
• Simple menu-driven WYSIWYG message creation and editing
• QuickSwitch® message selection and editing using a barcode scanner
• USB port for copy and back-up of message and printer settings, and for easy transfer of messages between printers
Physical characteristics
• Curved stainless steel casing with minimal dirt traps
• IP55 (washdown) as standard and IP65 (dust proof) as optional
• Weighs only 21kg
• No factory air required |
